Dipole antenna
The dipole antenna is a very simple and common type of antenna. The dipole antenna has two, often identical, conductive elements. The antenna has a total length of 1/2 wavelength.
Formulas
![Schematic](/media/schematics/dipole.png)
![](/shared/media/generated/c6d35b889d7b.png)
![](/shared/media/generated/bb4b63bc71a1.png)
![](/shared/media/generated/76eb837eb855.png)
l is the symbol for length and is measured in meter (m).
f is the frequency in megahertz (MHz).
Calculator
Enter two values to calculate the third.
